Fremco

Nanoflow Rapid

SKU: 101-240325001
E-number:

Battery‑Powered Fiber Blowing Machine with Torque Control

This battery‑powered fiber blowing machine is designed for safe and efficient installation of fiber optic cables and micro‑ducts in access and distribution networks. The machine combines adjustable clamping force with advanced fiber protection technology, ensuring controlled installation without risk of fiber damage. Its compact, tool‑free design makes it suitable for both indoor and outdoor use, particularly in locations without access to mains power.
The machine features a secure, non‑damaging grip around the fiber or cable, tested in accordance with relevant IEC standards. Installation is fully tool‑free, allowing quick setup and rapid opening and closing by hand. Blowing speed and torque are continuously adjustable, enabling precise adaptation to different fiber types, duct sizes, and installation conditions.
An integrated torque monitoring system provides active protection during operation. If the maximum recommended fiber load is exceeded, the preset torque limit immediately stops the blowing process, preventing overstressing or damage to the fiber. The battery‑driven design ensures independence from 100V/240V power supplies, making the machine ideal for field installations, remote sites, and temporary work areas.

Key Benefits:
  • Adjustable clamping force with secure, fiber‑safe grip
  • Tool‑free installation and quick manual opening/closing
  • Fiber protection technology tested in accordance with IEC standards
  • Adjustable speed and torque for controlled blowing performance
  • Automatic shutdown if preset torque limit is exceeded
  • Battery‑powered operation, independent of mains voltage

Measurements and weight attributes

Width (mm): 104

Depth (mm): 139

Height (mm): 212

Weight (kg): 3.5

Pull line diameter Ø (mm):

Pull line längd (m):

Break point (kg):

Break load (kg):

Grip length (mm):

Cable area max (mm2):

Cable diameter min Ø (mm): 0,8

Cabler diameter max Ø (mm): 4,5

Max diameter Ø (mm):

Max load (kg):

Stored measurement (mm):

Drum diameter min internal Ø (mm):

Drum diameter max internal Ø (mm):

Drum diameter max external Ø (mm):

Service weight (kg):

Drum width max (mm):

Drum diameter min Ø (mm):

Drum diameter max Ø (mm):

Drum center hole min (mm):

Drum center hole max (mm):

Drum size Ø:

Total weight (kg):

Total length (mm):

Pressure max (kg): 2.0

Outer diameter ring max Ø (mm):

Produktegenskaper

ETIM-klass: EC002413

Tullstat. nr: 84798900

Arbetstemperaturområde:

Densitet:

Diameter (mm):

Distans: 1200

Draghastighet max (m/min):

Dragkraft max (kp):

Draglina (typ):

Drivkälla:

Dukt: 3-12,7

Flöde max (l/min):

Frekvens (kHz):

Färg:

Gänga:

Gradering:

Kraft (kN):

Ljudnivå dB (A):

Luftflöde (l/min):

Lufttryck:

Material:

Motor:

pH-värde:

Räckvidd fri luft (m):

Stativ (typ):

Storlek:

Temperaturområde:

Töjning %:

Trumbroms:

Tryck max (bar):

Tryckhastighet max (m/min): 125.0

Viskositet (cP):
