Miniflow1200
Miniflow1200
Fremco

Miniflow Rapid

SKU: 101-10031
E-number:

Multiflow RAPID is a hydraulic fiber blowing machine designed for fast and safe fiber installation in demanding environments. Its robust construction in stainless steel and anodized aluminum ensures a long service life and stable operation even under tough conditions.

The machine is equipped with an integrated electronic counter and tachometer, making installation both precise and easy to monitor. The counter is easy to read, durable, and built to withstand heavy daily use.

An advanced cable protection system continuously monitors the applied pressure on the fiber cable. The system automatically stops the process if the load approaches critical levels—effectively reducing the risk of cable damage. Multiflow RAPID is also highly flexible and can be quickly adapted to different cable and duct sizes.

With a blowing speed of up to 100 m/min and installation distances of up to 3.5 km, this is a compact machine with impressive capacity.


  • Maximum safety: Automatic monitoring system that protects the cable from damage.
  • High efficiency: Blows up to 100 m/min over distances of up to 3.5 km.
  • Robust construction: Stainless steel and anodized aluminum for harsh working environments.
  • Precise control: Built-in electronic counter and tachometer.
  • Flexible: Quick adaptation to different cable and duct sizes.

Measurements and weight attributes

Width (mm): 225

Depth (mm):

Height (mm): 210

Weight (kg): 26.3

Pull line diameter Ø (mm):

Pull line längd (m):

Break point (kg):

Break load (kg):

Grip length (mm):

Cable area max (mm2):

Cable diameter min Ø (mm): 3

Cabler diameter max Ø (mm): 12

Max diameter Ø (mm):

Max load (kg):

Stored measurement (mm):

Drum diameter min internal Ø (mm): 7

Drum diameter max internal Ø (mm): 20

Drum diameter max external Ø (mm):

Service weight (kg):

Drum width max (mm):

Drum diameter min Ø (mm):

Drum diameter max Ø (mm):

Drum center hole min (mm):

Drum center hole max (mm):

Drum size Ø:

Total weight (kg):

Total length (mm):

Pressure max (kg): 40.0

Outer diameter ring max Ø (mm):

Product attributes

ETIM-class: EC002390

Tullstat. nr: 84798997

Working temperature range:

Density:

Diameter (mm):

Distanse: 1500 m

Pull speed max (m/min):

Pull force max (kp):

Pull line (typ):

Drive source:

Duct: 7-20

Flow max (l/min):

Frequency (kHz):

Color:

Thread:

Grading:  test

Force (kN):

Sound level dB (A):

Air flow (l/min):

Air pressure: 1000 L/pr. m

Material:

Motor:

pH value:

Reach in free air (m):

Stand (type):

Size:

Temperature range: > 60 °C

Elongation%:

Drum break:

Pressure max (bar): 16

Pressure speed max (m/min):

Viscosity (cP):
