Overhead Roller Outer Angles
Hanging Cable Roller with Three Rollers – for overhead pulling at external angles
The Hanging Cable Roller with three rollers is designed for controlled and cable‑safe overhead pulling at external angles, where the cable is guided around an outer radius. It is used in suspended installations such as poles, gantries, cable bridges, and overhead structures where proper cable support and bending control are critical.
The unit is equipped with three ball‑bearing rollers that provide stable cable guidance and even load distribution through the angle. The triple‑roller configuration ensures correct cable contact even at larger angles and higher pulling forces, while minimizing friction and point loading. This design helps protect the cable sheath and maintain the correct bending radius throughout the pulling operation.
The Hanging Cable Roller is intended for professional installation of LV, MV, and selected HV cables and can be integrated into complete cable routing systems together with straight, corner, and double hanging rollers.
Key Benefits:
– Three ball‑bearing rollers for stable cable guidance
– Designed for external angles in overhead pulling
– Even load distribution and low friction
– Reduced risk of cable sheath damage
– Suitable for suspended cable installations
Measurements and weight attributes
Width (mm):
Depth (mm):
Height (mm):
Weight (kg): 6.5
Pull line diameter Ø (mm):
Pull line längd (m):
Break point (kg):
Break load (kg):
Grip length (mm):
Cable area max (mm2):
Cable diameter min Ø (mm):
Cabler diameter max Ø (mm): 50
Max diameter Ø (mm):
Max load (kg): 1000
Stored measurement (mm):
Drum diameter min internal Ø (mm):
Drum diameter max internal Ø (mm):
Drum diameter max external Ø (mm):
Service weight (kg):
Drum width max (mm):
Drum diameter min Ø (mm):
Drum diameter max Ø (mm):
Drum center hole min (mm):
Drum center hole max (mm):
Drum size Ø:
Total weight (kg):
Total length (mm):
Pressure max (kg):
Outer diameter ring max Ø (mm):
Product attributes
ETIM-class: EC000322
Tullstat. nr: 84283990
