Cable Jacket Remover ABI1

SKU: I-ABI1
E-number:
The ABI1 cable jacket remover is a compact and versatile tool developed for fast and precise removal of outer sheaths on smaller diameter cables. With an application range of Ø4.5–29 mm and cutting depth up to 3 mm, it is ideal for PVC and rubber insulated cables commonly used in LV installations and control wiring.
The tool is equipped with a hardened steel blade featuring a special grinding profile to ensure clean and accurate sheath removal without damaging underlying layers. It supports round, longitudinal, and spiral cuts, providing flexibility for different stripping methods and installation situations. Cutting depth is precisely adjustable in 0.1 mm increments via a rotary knob, allowing controlled operation across varying insulation thicknesses.
The axial pulling design prevents tilting during longitudinal cuts, ensuring stable handling and consistent results. A built-in locking system secures the tool during longitudinal cutting, reducing the risk of blade damage due to incorrect use. Its low-friction contact surface enables smooth movement along the cable without resistance, while the ergonomic and lightweight design ensures comfortable use in repetitive tasks and confined spaces.

Key Benefits:
  • Precise sheath removal with adjustable depth (0.1 mm increments)
  • Supports round, longitudinal, and spiral cutting
  • Stable operation without tilting during longitudinal cuts
  • Hardened, precision-ground blade for clean stripping
  • Compact, ergonomic design for easy handling

Measurements and weight attributes

Width (mm):

Depth (mm): 140

Height (mm):

Weight (kg): 0.15

Pull line diameter Ø (mm):

Pull line längd (m):

Break point (kg):

Break load (kg):

Grip length (mm):

Cable area max (mm2):

Cable diameter min Ø (mm): 4,5

Cabler diameter max Ø (mm): 29

Max diameter Ø (mm):

Max load (kg):

Stored measurement (mm):

Drum diameter min internal Ø (mm):

Drum diameter max internal Ø (mm):

Drum diameter max external Ø (mm):

Service weight (kg):

Drum width max (mm):

Drum diameter min Ø (mm):

Drum diameter max Ø (mm):

Drum center hole min (mm):

Drum center hole max (mm):

Drum size Ø:

Total weight (kg):

Total length (mm):

Pressure max (kg):

Outer diameter ring max Ø (mm):

Product attributes

ETIM-class: EC002123

Tullstat. nr: 82055900

Working temperature range:

Density:

Diameter (mm):

Distanse:

Pull speed max (m/min):

Pull force max (kp):

Pull line (typ):

Drive source:

Duct:

Flow max (l/min):

Frequency (kHz):

Color:

Thread:

Grading:

Force (kN):

Sound level dB (A):

Air flow (l/min):

Air pressure:

Material:

Motor:

pH value:

Reach in free air (m):

Stand (type):

Size:

Temperature range:

Elongation%:

Drum break:

Pressure max (bar):

Pressure speed max (m/min):

Viscosity (cP):
